Cisco Linksys E4200 User Manual

Linksys E4200
Appendix B: How to Connect and Access USB Storage
2 . In the Address field, enter the default IP address of the
router: \\192.168.1.1
2 . In the Address field, enter the default IP address of the
router: \\192.168.1.1
Enter Local IP Address of Router
Enter Local IP Address of Router
NOTE: Another option is to use the Device Name
(Disk) of the router . In the Address field, enter:
\\Cisco followed by the last five digits of the
router’s serial number . If you used the setup
software for installation, then enter the name of
your wireless network (up to 15 characters) in
the Address field .
3 . Double-click the shared folder .
NOTE: Another option is to use the Device Name
(Disk) of the router . In the Address field, enter:
\\Cisco followed by the last five digits of the
router’s serial number . If you used the setup
software for installation, then enter the name of
your wireless network (up to 15 characters) in
the Address field .
3 . Right-click the folder you want to map, and click Map
Network Drive .
Double-Click Shared Folder
NOTE: If the login screen appears, enter your
account username and password . Click OK .
Map Network Drive
4 . From the Drive drop-down menu, select an available
drive letter .
Map a Drive
1 . On your desktop, double-click the My Computer icon .
My Computer Icon
NOTE: If the My Computer icon is not displayed,
then go to Start > All Programs > Accessories
> Windows Explorer .
Select Drive Letter
NOTE: If the login screen appears, enter your
account username and password . Click OK .
Maximum Performance Wireless-N Router
54

Cisco Linksys E4200 Specifications

General

Wireless Standard	802.11a/b/g/n
Frequency Bands	2.4 GHz and 5 GHz
USB Ports	1 x USB 2.0
Antenna Type	Internal
Wired Speed	10/100/1000 Mbps
Ethernet Ports	4 x 10/100/1000 Mbps LAN
Security Features	WPA/WPA2
Maximum Data Rate	450 Mbps (5 GHz)
Weight	0.32 kg
