• Ensure that circuits are sized according to local and national codes.
For North America, the 650-W power supplies require a 15-A circuit. If you are using a 200 or 240 VAC
power source in North America, the circuit must be protected by a two-pole circuit breaker.
To prevent loss of input power, ensure that the total maximum loads on the circuits
supplying power to the switch are within current ratings for wiring and breakers.
Caution
• As you install and configure the switch, record the information listed in the Site Planning and Maintenance
Records section.
Unpacking and Inspecting the Switch
When handling switch components, wear an ESD strap and handle modules using only the carrier edges. An
ESD socket is provided on the chassis. For an ESD socket to be effective, the chassis must be grounded
through the power cable, the chassis ground, or the metal-to-metal connection with a grounded rack.
Caution
Retain the shipping container in case the chassis has to be shipped in the future.
Tip
The switch is thoroughly inspected before shipment. If any damage occurs during transportation, or if any
item is missing, contact your customer representative immediately. If you purchased Cisco support through
a Cisco reseller, contact the reseller directly. If you purchased support directly from Cisco, contact Cisco
Technical Support.
Note
To inspect the shipment, follow these steps:
1. Compare the shipment to the equipment list provided by your customer service representative and verify
that you have received all items, including the following:
• Grounding lug kit
• Rack-mount kit
• ESD wrist strap
• Cables and connectors
• Optional items, if any, ordered
2. Check for damage and report any discrepancies or damage, to your customer service representative. Have
the following information ready:
• Invoice number of shipper (see packing slip)
• Model and serial number of the damaged unit
• Description of damage
Installing a Cisco MDS 9132T Switch
6
Installing a Cisco MDS 9132T Switch
Unpacking and Inspecting the Switch
