Cisco ME 3400 - Attaching the Brackets

14
Attaching the Brackets
Use four Phillips flat-head screws to attach the long side of the brackets to the switches in one of three
mounting positions (for all but the Cisco ME 3400G-2CS switch):
1
Front-mounting position
3
Mid-rack mounting position (telco rack)
2
Number-8 Phillips flat-head screws
4
Rear-mounting position
