Cisco ME 3400E

11
Rack-Mount the Switch
Use the black Phillips machine screw to attach the cable guide to the left or right bracket and the supplied screws to attach the
brackets to the rack:
• Cisco ME 3400E-24TS-M and Cisco ME 3400EG-12CS-M switches:
• Cisco ME 3400EG-2CS-A switch:
1
Black Phillips machine screw
2
Cable guide and screw
1
Black Phillips machine screw
3
Number-10 Phillips truss-head screws
2
Cable guide
1
2
280840
2
3
1
280841
