Cisco NCS 55A1-36H

•
Cisco NCS 55A1-36H-S, NCS 5502 and NCS 5502-SE: Attach one end of the shelf ground cable (#6 AWG cable)
to the grounding cover plate using the specified dual-hole lug connector.
Figure 15: NCS 55A1-36H-S Ground Lug
M4 x 6mm pan-head screws2Grounding lug1
Figure 16: NCS 5502 Ground Lug
M4 x 8mm pan-head screws2Grounding lug1
Hardware Installation Guide for Cisco NCS 5500 Series Fixed-Port Routers
27
Install the Chassis
Ground the Chassis
