Chassis Installation Procedures for Cisco 2800 Series Routers
OL-5786-03
Installing Modules and Interface Cards
Figure 2 Chassis Slot Locations in Cisco 2811 Routers
Figure 3 Chassis Slot Locations in Cisco 2821 Routers
1 Screw holes for ground lug 5 High-speed WAN interface card slot 1
2 Fast Ethernet port 0/0 6 High-speed WAN interface card slot 2
3 Fast Ethernet port 0/1 7 High-speed WAN interface card slot 3
4 High-speed WAN interface card slot 0 8 Network module enhanced (NME) slot
1
1. The network module slot is compatible with Cisco network modules of type NM (network module) and NME (network module enhanced).
1 Gigabit Ethernet port 0/0 6 High-speed WAN interface card slot 3
2 Gigabit Ethernet port 0/1 7 Extension voice module slot
3 High-speed WAN interface card slot 0 8 Network module enhanced (NME) slot
1
1. The network module slot is compatible with Cisco network modules of type NM (network module), NME (network module enhanced), and NME-X
(enhanced extended).
4 High-speed WAN interface card slot 1 9 Screw holes for ground lug
5 High-speed WAN interface card slot 2
A= ACT
FE 0/1
PVDM1 PVDM0 AIM1 AIM0
FE 0/0
S= SPEED
A= FDX
A= LINK
A
F
S
L
A
F
S
L
H
W
I
C
2
H
W
I
C
0
H
W
I
C
3
H
W
I
C
1
1
23
95556
45
67
1
8
95572
12
6 4 3 75
9
A= ACT
GE 0/1
PVDM2 PVDM1 PVDM0 AIM1 AIM0
GE 0/0
S= SPEED
A= FDX
A= LINK
A
F
S
L
A
F
S
L
EVM 2 ONLY
1
8
