Cisco RNG200 User Manual

18
Connecting an External SATA Hard Disk Drive (optional)
Complete the following steps to install an external SATA (eSATA) drive.
1. Verify that both the DVR and the eSATA drive are unplugged from power.
2. Connect the data cable for the eSATA drive to the DVR.
3. Plug in power to the eSATA drive.
4. Plug in the DVR power cord, and then turn on the DVR.
5. Follow the on-screen instructions. One of the following occurs:
• If it is a new eSATA drive or one used on another device, you will be asked to format it.
• If the drive is formatted and will work with this DVR, you will get a confi rmation that the drive is working.
WARNING: Electric shock hazard! Unplug all electronic devices before connecting or disconnecting
any device cables to the set-top.
How the eSATA Drive Works with Your DVR
An eSATA drive is an extension of the internal hard drive of the DVR; it is not an archival device. Programs recorded
to the eSATA drive can be played back on the DVR originally connected to the eSATA drive. For instance, you cannot
record programs to the eSATA drive, remove the drive, and then connect it to a computer or a different DVR for
playing back programs.
Some programs will record to the DVR internal hard drive and some will record to the eSATA drive, depending on the
space available. The DVR selects the drive that has enough space to record the entire program; a program is not split
between the internal and external drives.
RNG200N
T
HIS DEVICE IS INTENDED TO BE ATTACHED
T
O A RECEIVER THAT IS NOT USED TO
RECEIVE OVER-THE-AIR BROADCAST
SIGNALS. CONNECTION OF THIS DEVICE
IN ANY OTHER FASHION MAY CAUSE
HARMFUL INTERFERENCE TO RADIO
COMMUNICATIONS AND IS IN VIOLATION
OF THE FCC RULES, PART 15
.
CABLE OU
T
S-VIDE
O
OU
T
U
SB 2.0
OPTICAL
AUDIO
OU
T
M
ULTI-STREA
M
C
ABLE
C
AR
D
V
IDEO
L
R
D
IGITAL
AUDIO
IR
AVI S: RISQUE DE CHO
C
E
LECTRIQUE NE PAS OUVRI
R
1
39
4
E
THERNE
T
C
ABLE I
N
CATV CONVERTER
M
ADE IN MEXICO
L
ISTED 36M
W
V
IDEO PRODUC
T
eCM MAC: 001AC3F4F757
STB RF MAC: 001AC3F$F756
STB SN: SABPQBQGD
MC
ARD
S
N: PX
C
PRP
S
L
V
MC
ARD MA
C
: 00 1BD7
3
E17D
9
CAUTION
RI
S
K OF ELECTRIC
S
HOCK
D
O NOT OPE
N
CABLE IN
OUTPUT
Pb
Y
Pr
L
R
eSATA
120VAC
60Hz 80W
120 VAC
60Hz 4.2A
500W
SATA
Cable
Input
To
Unswitched
Wall Outlet
To
Unswitched
Wall Outlet
External SATA
Hard Disk Drive
T13991
