Cisco SCE 8000 Installation Guide

12
MGSCP Topologies
In an MGSCP deployment, the exact cabling scheme depends on the number and arrangement of ports in the EtherChannel in
the Cisco 7600 Series router. It is, therefore, not possible to provide exact cabling schemes.
3/3/0 (cascade port) Port 3/2/0 on Cisco SCE 8000 #2
This port on SCE8000 #2 Connects to...
3/0/0 Subscriber-side network element
3/1/0 Network-side network element
3/2/0 (cascade port) Port 3/3/0 on Cisco SCE 8000 #1
3/3/0 (cascade port) Port 3/2/0 on Cisco SCE 8000 #1
Table 4 Optical Bypass Connectivity: Single Link
Optical Bypass Port Connects to...
A Subscriber-side network element
B Network-side network element
C Cisco SCE platform port 3/0/0
D Cisco SCE platform port 3/1/0
CTRL Left-hand External Bypass port on the Cisco SCE 8000-SCM-E module.
Table 5 Optical Bypass Connectivity: Dual Link
Port on Optical Bypass #1 Connects to...
A Subscriber-side network element
B Network-side network element
C Cisco SCE platform port 3/0/0
D Cisco SCE platform port 3/1/0
CTRL Left-hand External Bypass port on the Cisco SCE 8000-SCM-E module.
Port on Optical Bypass #2 Connects to...
A Subscriber-side network element
B Network-side network element
C Cisco SCE platform port 3/2/0
D Cisco SCE platform port 3/3/0
CTRL Right-hand External Bypass port on the SCE 8000-SCM-E module.
Table 3 Cascade Connectivity (continued)
This port on Cisco SCE 8000 #1 Connects to...
