• Cisco Unified Computing System (UCS) server model R210-2121605 with a Intel(R) Xeon(R) X5570 2.93-GHz CPU with
eight Cores (minimum memory 4 GB).
The machine should conform to the system requirements listed in Table 9 and Table 10.
Note The specifications listed in Table 9 are minimal. Verify the specifications to guarantee specific performance and capacity
requirements.
For the hardware and software system requirements for the Veritas Cluster Server, see the Veritas Cluster Server chapter of the
Cisco Service Control Management Suite Subscriber Manager User Guide.
Note We recommend that you apply the latest patches from Red Hat.
Table 9 Minimal System Hardware Requirements
Item Requirement
CPU The CPU requirements are:
• Intel processor, 64 bit, minimum 1 GHz (for Linux Red Hat)
RAM Minimum 1 GB
Free Disk Space Minimum 3 GB total, of which:
• Minimum 1 GB free on partition where VARDIR (SM database repository) is installed
• Minimum 0.5 GB free on partition where PCUBEDIR (Subscriber Manager files) is
installed
• Minimum 200 MB free on partition where /tmp is mounted
Network Interface Depends on whether the configuration includes a cluster:
• Without cluster—One (1) 100BASE-T Ethernet
• With cluster—Six (6) 100BASE-T Ethernet
CD-ROM drive Recommended
Table 10 Red Hat System Software Requirements
Item Requirement
OS Red Hat Enterprise Linux AS/ES 5.5 and later, or 6.x; currently, only 64-bit version is
supported.
Red Hat Core Installation.
System Packages Mandatory:
• GNU Bourne-Again shell (bash-2.05b-29.i386.rpm).
• GNU Data Compression Program (gzip-1.3.3-9.i386.rpm).
• File compression and packaging utility (zip-2.3-16.i386.rpm).
• Standard C++ libraries for Red Hat Linux 6.2 backward compatibility
(compat-gcc-7.3-2.96.122.i386.rpm).
• sudo (superuser do) package.
For integrating with the C API:
• GNU cc and gcc C compilers (gcc-3.2.3-20.i386.rpm).
• C++ support for the GNU gcc compiler (gcc-3.2.3-20.i386.rpm).
