Port Management
Configuring Link Aggregation
Cisco Small Business 200 Series Smart Switch Administration Guide 111
9
Setting Port LACP Parameter Settings
The LACP page displays and enables configuration of the LACP System Priority,
LACP timeout, and LACP port priority. LACP timeout is a per port parameter, and is
the time interval between the sending and receiving of consecutive LACP PDUs.
With all factors equal, when the LAG is configured with more candidate ports than
the maximum number of active ports allowed, the switch selects ports as active
from the dynamic LAG that has the highest priority
NOTE The LACP setting is irrelevant on ports that are not members of a dynamic LAG.
To d e f i n e t h e L A C P s e t t i n g s :
STEP 1 Click Port Management > Link Aggregation > LACP. The LACP page opens.
STEP 2 Enter the LACP System Priority. See Configuring LACP.
STEP 3 Select a port, and click Edit. The Edit LACP page opens.
STEP 4 Enter the values for the following fields:
• Interface—Select the port number to which timeout and priority values are
assigned.
• LACP Port Priority—Enter the LACP priority value for the port. See Setting
Port LACP Parameter Settings.
• LACP Timeout—Select the periodic transmissions of LACP PDUs, which
occur at either a long or short transmission speed, depending upon the
expressed LACP timeout preference.
STEP 5 Click Apply. The Running Configuration file is updated.
