Viewing Statistics
Viewing Etherlike Statistics
Cisco Small Business 200 Series Smart Switch Administration Guide 19
2
- 60 Sec—Statistics are refreshed every 60 seconds.
The Receive Statistics area displays information about incoming packets.
• Total By tes (Octet s)—Octets received, including bad packets and FCS
octets, but excluding framing bits.
• Unicast Packets—Good Unicast packets received.
• Multicast Packets—Good Multicast packets received.
• Broadcast Packets—Good Broadcast packets received.
• Packets with Errors—Packets with errors received.
The Transmit Statistics area displays information about outgoing packets.
• Total By tes (Octet s)—Octets transmitted, including bad packets and FCS
octets, but excluding framing bits.
• Unicast Packets—Good Unicast packets transmitted.
• Multicast Packets—Good Multicast packets transmitted.
• Broadcast Packets—Good Broadcast packets transmitted.
To clear statistics counters:
• Click Clear Interface Counters to clear counters for the interface displayed.
• Click Clear All Interface Counters to clear counters for all interfaces.
Viewing Etherlike Statistics
The Etherlike page
displays statistics per port according to the Etherlike MIB
standard definition. The refresh rate of the information can be selected. This page
provides more detailed information regarding errors in the physical layer (Layer 1),
which might disrupt traffic.
To view Etherlike Statistics and/or set the refresh rate:
STEP 1 Click Status and Statistics > Etherlike. The Etherlike page is displayed.
STEP 2 Enter the parameters.
