Smartports
Auto Smartport
Cisco Small Business 200 Series Smart Switch Administration Guide 127
10
Using CDP/LLDP Information to Identify Smartport Types
The switch detects the type of device attached to the port, based on the CDP/
LLDP capabilities.
This mapping is shown in the following tables:
CDP Capabilities Mapping to Smartport Type
Capability Name CDP Bit Smartport Type
Router 0x01 Router
TB Bridge 0x02 Wireless Access Point
SR Bridge 0x04 Ignore
Switch 0x08 Switch
Host 0x10 Host
IGMP conditional filtering 0x20 Ignore
Repeater 0x40 Ignore
VoIP Phone 0x80 ip_phone
Remotely-Managed Device 0x100 Ignore
CAST Phone Port 0x200 Ignore
Two-Port MAC Relay 0x400 Ignore
LLDP Capabilities Mapping to Smartport Type
Capability Name LLDP Bit Smartport Type
Other 1 Ignore
Repeater IETF RFC 2108 2 Ignore
MAC Bridge IEEE Std. 802.1D 3 Switch
WLAN Access Point IEEE Std. 802.11
MIB
4 Wireless Access
Point
Router IETF RFC 1812 5 Router
Telephone IETF RFC 4293 6 ip_phone
