Managing Power-over-Ethernet Devices
Configuring the PoE Power, Priority, and Class
Cisco Small Business 200 Series Smart Switch Administration Guide 155
11
• Overload Counter—Displays the total number of power overload
occurrences.
• Short Counter—Displays the total number of power shortage occurrences.
• Denied Counter—Displays number of times the powered device was
denied power.
• Absent Counter—Displays the number of times that power was stopped to
the powered device, because the powered device was no longer detected.
• Invalid Signature Counter—Displays the times an invalid signature was
received. Signatures are the means by which the powered device identifies
itself to the PSE. Signatures are generated during powered device
detection, classification, or maintenance.
STEP 4 Click Apply. The PoE settings for the port are written to the Running Configuration
file.
