DescriptionFeature
Rear panel:
• One 1-Gb Ethernet dedicated management port (RJ-45
connector)
• Two 1-Gb/10-Gb BASE-T Ethernet LAN ports (RJ-45
connectors)
The dual LAN ports can support 1 Gbps and 10 Gbps,
depending on the link partner capability.
• One RS-232 serial port (RJ-45 connector)
• One VGA video connector port (DB-15 connector)
• Two USB 3.0 ports
Front panel:
• One front-panel keyboard/video/mouse (KVM) connector
that is used with the KVM cable, which provides two USB
2.0, one VGA, and one DB-9 serial connector.
Network and management I/O
One dedicated socket (x16 PCIe lane) that can be used to add an
mLOM card for additional rear-panel connectivity.
Modular LOM
One power supply:
• AC power supplies 1050 W AC each
Power
The advanced configuration and power interface (ACPI) 4.0
standard is supported.
ACPI
Seven hot-swappable fan modules for front-to-rear cooling.Cooling
Two horizontal PCIe expansion slots on a PCIe riser assembly.
See PCIe Slot Specifications, on page 60 for specifications of the
slots.
PCIe I/O
The PCIe bus slots in this server support the InfiniBand
architecture.
InfiniBand
The server is orderable in three different versions, each with a
different front panel/drive-backplane configuration.
• SE-CL-L3 , Small form-factor (SFF) drives, with 10-drive
backplane. Supports up to 10 2.5-inch SAS/SATA drives.
Drive bays 1 and 2 support NVMe SSDs.
Storage, front-panel
Cisco Application Services Engine Hardware Installation Guide
7
Overview
Summary of Server Features
