DescriptionFeature
The server has these internal storage options:
• One USB port on the motherboard.
• One micro-SD card socket on PCIe riser 1.
• Mini-storage module socket, optionally with either:
• SD card module. Supports up to two SD cards.
• M.2 SSD module. Supports either two SATA M.2 SSDs
or two NVMe M.2 SSDs.
• Cisco Boot-Optimized M.2 RAID Controller (module
with two slots for SATA M.2 drives, plus an integrated
SATA RAID controller that can control the two SATA
M.2 drives in a RAID 1 array)
Storage, internal
The server has a dedicated internal mRAID riser that supports
one of the following storage-controller options:
• A PCIe-style Cisco modular RAID controller card
(SAS/SATA).
• A PCIe-style interposer card for the server’s embedded
SATA RAID controller.
For a detailed list of storage controller options, see Supported
Storage Controllers and Cables, on page 91.
Storage management
The server has a mounting bracket near the cooling fans for the
supercap unit that is used with the Cisco modular RAID controller
card.
RAID backup
Integrated VGA video.Integrated video
Cisco Application Services Engine Hardware Installation Guide
8
Overview
Summary of Server Features
