Administration: Discovery
Discover - LLDP
117 Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x
8
LLDP Port Status
The LLDP Port Status page contains the LLDP global information for every port.
STEP 1 To view the LLDP port status, click Administration > Discovery - LLDP > LLDP Port
Status.
Information for all ports, including the OOB port is displayed.
STEP 2 Select a specific port and click LLDP Local Information Detail to see the details of the
LLDP and LLDP-MED TLVs sent out to the port.
STEP 3 Select a specific port and click LLDP Neighbor Information Detail to see the details of the
LLDP and LLDP-MED TLVs received from the port.
• LLDP Port Status Global Information
• Chassis ID Subtype—Type of chassis ID (for example, MAC address).
• Chassis ID—Identifier of chassis. Where the chassis ID subtype is a MAC address, the
MAC address of the device appears.
• System Name—Name of device.
• System Description—Description of the device (in alpha-numeric format).
• Supported System Capabilities—Primary functions of the device, such as Bridge,
WLAN AP, or Router.
• Enabled System Capabilities—Primary enabled function(s) of the device.
• Port ID Subtype—Type of the port identifier that is shown.
• LLDP Port Status Table
• Interface—Port identifier.
• LLDP Status—LLDP publishing option.
• LLDP MED Status—Enabled or disabled.
• Local PoE ((Power Type, Power Source, Power Priority, Power Value)—Local PoE
information advertised.
• Remote PoE (Power Type, Power Source, Power Priority, Power Value)—PoE
information advertised by the neighbor.
• # of neighbors—Number of neighbors discovered.
