Security: 802.1X Authentication
Authenticated Hosts
Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x 326
17
To define 802.1X advanced settings for ports:
STEP 1 Click Security > 802.1X/MAC/Web Authentication > Host and Session Authentication.
The authentication parameters are described for all ports. All fields except the following are
described in the Edit page.
• Number of Violations—Displays the number of packets that arrive on the interface in
single-host mode, from a host whose MAC address is not the supplicant MAC address.
STEP 2 Select a port, and click Edit.
STEP 3 Enter the parameters.
• Interface—Enter a port number for which host authentication is enabled. The OOB port
is included.
• Host Authentication—Select one of the modes. These modes are described above in
Port Host Modes.
Single Host Violation Settings (only displayed if host authentication is Single Host):
• Action on Violation—Select the action to be applied to packets arriving in Single
Session/Single Host mode, from a host whose MAC address is not the supplicant MAC
address. The options are:
- Protect (Discard)—Discards the packets.
- Restrict (Forward)—Forwards the packets.
- Shutdown—Discards the packets and shuts down the port. The ports remains shut
down until reactivated, or until the device is rebooted.
• Traps—Select to enable traps.
• Trap Frequency—Defines how often traps are sent to the host. This field can be
defined only if multiple hosts are disabled.
STEP 4 Click Apply. The settings are written to the Running Configuration file.
Authenticated Hosts
To view details about authenticated users, click Security > 802.1X/MAC/Web
Authentication > Authenticated Hosts.
