Port Management
PoE
173 Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x
9
To view the PoE consumption trend on the device and define settings for the view:
STEP 1 Click Port Management > PoE > Statistics.
STEP 2 Select the unit and port in the Unit and Port fields.
STEP 3 Select the Refresh Rate.
STEP 4 The following fields are displayed for the selected interface:
Consumption History
• Average Consumption over Last Hour—Average of all PoE consumption readings in
the last hour.
• Average Consumption over Last Day—Average of all PoE consumption readings in
the last day.
• Average Consumption over Last Week—Average of all PoE consumption readings in
the last week.
PoE Event Counters
• Overload Counter—Number of overload conditions detected.
• Short Counter—Number of short conditions detected
• Denied Counter—Number of denied conditions detected
• Absent Counter—Number of absent conditions detected
• Invalid Signature Counter—Number of invalid signature conditions detected
The following operations can be performed in the main page:
• Clear Event Counters—Clear the displayed event counters.
• View All Interfaces Statistics—Display the above statistics for all interfaces
• View Interface History Graph—Display the counters in graph format.
• Refresh—Refresh the displayed counters.
The following operations can be performed by clicking View All Interfaces Statistics:
• Clear Event Counters—Clear the displayed event counters.
• View Interfaces Statistics—Display the above statistics for a selected interface
• View Interface History Graph—Display the counters in graph format for a selected
interface
