IP Configuration
IPv6 Management and Interfaces
Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x 296
15
- Auto—Automatically selects the minimum IPv4 address from among all of its
configured IPv4 interfaces as the source address for packets sent on the tunnel
interface.
If the minimum IPv4 address is removed from the interface (removed at all or
moved to another interface), the next minimum IPv4 address is selected as the local
IPv4 address.
- IPv4 Address (called Source Address in the main page)—Enter the IPv4 address of
the interface that will be used as the source address of the tunnel.
- Manual—Select the interface whose IPv4 address will be used as the source address
of the tunnel.
• Destination—(For manual tunnel only) Select one of the following options to specify
the destination address of the tunnel:
- Host Name—DNS name of the remote host.
- IPv4 Address—IPv4 address of the remote host.
• ISATAP Router Name— (For ISATAP tunnels only) Select one of the following
options to configure a global string that represents a specific automatic tunnel router
domain name.
- Use Default—This is always ISATAP.
- User Defined—Enter the router’s domain name.
STEP 7 Click Apply. The tunnel is saved to the Running Configuration file.
NOTE For a 350XG device and the 550 family of devices, to shut down a tunnel, click Edit and
uncheck Tunnel State. To disable traps, click Edit and uncheck Link Status SNMP Traps.
IPv6 Addresses
To assign an IPv6 address to an IPv6 Interface:
STEP 1 Click IP Configuration > IPv6 Management and Interfaces > IPv6 Addresses.
STEP 2 To filter the table, select an interface name, and click Go. The interface appears in the IPv6
Address Table. These fields are described in the Add page except for the following fields:
• DAD Status—Displays whether Duplicate Access Detection is active or not.
• Type—Displays the type of the IPv6 address.
