IP Configuration
Domain Name System
Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x 316
15
• IPv6 Address Type—Select the IPv6 address type (if IPv6 is used). The options are:
- Link Local—The IPv6 address uniquely identifies hosts on a single network link. A
link local address has a prefix of FE80, is not routable, and can be used for
communication only on the local network. Only one link local address is supported.
If a link local address exists on the interface, this entry replaces the address in the
configuration.
- Global—The IPv6 address is a global Unicast IPV6 type that is visible and
reachable from other networks.
• Link Local Interface—If the IPv6 address type is Link Local, select the interface
through which it is received.
• Host Name—Enter a user-defined host name or fully-qualified name. Host names are
restricted to the ASCII letters A through Z (case-insensitive), the digits 0 through 9, the
underscore and the hyphen. A period (.) is used to separate labels.
• IP Address—Enter a single address or up to eight associated IP addresses (IPv4 or
IPv6).
STEP 5 Click Apply. The settings are saved to the Running Configuration file.
