IP Configuration: RIPv2
Configuring RIP
Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x 404
17
• User Defined Metric—Enter the value of the metric.
STEP 7 Click Apply. The settings are written to the Running Configuration file.
RIPv2 Settings
To configure RIP on an IP interface:
STEP 1 Click IP Configuration > RIPv2 > RIPv2 Settings.
STEP 2 RIP parameters are displayed per IP interface. To add a new IP interface, click Add and enter
the following fields:
• IP Address—Select an IP interface defined on the Layer 2 interface.
• Shutdown—Keep RIP configuration on the interface, but set the interface to inactive.
• Passive—Specifies whether sending RIP route update messages is allowed on the
specified IP interface. If this field is not enabled, RIP updates are not sent (passive).
• Offset—Specifies the metric number of the specified IP interface. This reflects the
additional cost of using this interface, based on the speed of the interface.
• Default Route Advertisement—This option is defined globally in the RIPv2
Properties page. You can use the global definition or define this field for the specific
interface. The following options are available:
- Global—Use the global settings defined in the RIPv2 Properties. screen.
- Enable—Advertise the default route on this RIP interface.
- Disable—On this RIP interface, do not advertise the default route.
• Default Route Advertisement Metric—Enter the metric for the default route for this
interface.
• Authentication Mode—RIP authentication state (enable/disable) on a specified IP
interface. The following options are available:
- None—There is no authentication performed.
- Text—The key password entered below is used for authentication.
- MD5—The MD5 digest of the key chain selected below is used for authentication.
• Key Password—If Text was selected as the authentication type, enter the password to
be used.
