Security
Denial of Service Prevention
333 Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x
16
- Blocked—Traffic is not forwarded on this interface.
- Attacked—Attack was identified on this interface.
• Last Attack—Date of last SYN-FIN attack identified by the system and the system
action (Reported or Blocked and Reported).
Martian Addresses
The Martian Addresses page enables entering IP addresses that indicate an attack if they are
seen on the network. Packets from these addresses are discarded.
The device supports a set of reserved Martian addresses that are illegal from the point of view
of the IP protocol. The supported reserved Martian addresses are:
• Addresses defined to be illegal in the Martian Addresses page.
• Addresses that are illegal from the point of view of the protocol, such as loopback
addresses, including addresses within the following ranges:
- 0.0.0.0/8 (Except 0.0.0.0/32 as a Source Address)—Addresses in this block refer
to source hosts on this network.
- 127.0.0.0/8—Used as the Internet host loopback address.
- 192.0.2.0/24—Used as the TEST-NET in documentation and example codes.
- 224.0.0.0/4 (As a Source IP Address)—Used in IPv4 Multicast address
assignments, and was formerly known as Class D Address Space.
- 240.0.0.0/4 (Except 255.255.255.255/32 as a Destination Address)—Reserved
address range, and was formerly known as Class E Address Space.
You can also add new Martian Addresses for DoS prevention. Packets that have a Martian
addresses are discarded.
To define Martian addresses:
STEP 1 Click Security > Denial of Service Prevention > Martian Addresses.
STEP 2 Select Reserved Martian Addresses and click Apply to include the reserved Martian
Addresses in the System Level Prevention list.
STEP 3 To add a Martian address click Add.
STEP 4 Enter the parameters.
