Status and Statistics
Switched Port Analyzer (SPAN and RSPAN)
53 Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x
4
3. Define a reflector port (destination, egress port) and ensure that it is not a member of the
RSPAN VLAN.
4. Define the Destination Type as Remote VLAN.
5. Set Network Traffic to Enable.
Intermediate Switch(es)
1. Define the RSPAN VLAN. This RSPAN VLAN must be the same in the start, intermediate
and final switches.
2. Ensure that there are at least two ports that are members of the RSPAN VLAN. Traffic will
pass through the switch via the RSPAN VLAN.
Final Switch
1. Define the RSPAN VLAN. This RSPAN VLAN must be the same in the start, intermediate
and final switches.
2. Ensure that the source port, which is connected to the intermediate switch, is a member of
the RSPAN VLAN.
3. Define the Source Interface as Remote VLAN.
4. Define a destination port and make sure it is not in the RSPAN VLAN.
5. Define the Destination Type as Local Interface.
RSPAN VLANs
An RSPAN VLAN must be defined on the start, intermediate and final devices.
To configure a VLAN as an RSPAN VLAN:
STEP 1 Click Status and Statistics > SPAN & RSPAN > RSPAN VLANs.
The previously-defined RSPAN VLAN is displayed.
STEP 2 To configure a VLAN as an RSPAN VLAN, select it from the RSPAN VLAN dropdown list
of VLANs.
STEP 3 Click Apply.
