Horizon | Cisco 504 IP Phone Quick User Guide
© Gamma 2016. All rights reserved. Confidential.
Page 5 of 9
Your phone’s display and buttons
Feature
Description
1. Handset
Pick up to answer or make calls
2. Message Waiting
Indicator
- When lit:
- Red - you have a new voice mail message.
- Flashing red - you have an incoming call.
3. Screen
- Typically, this will display the:
- Date and time
- Phone station name
- Line extensions
- Softkey options
- Startup logo and screen saver.
4. Line keys
These indicate the status of the phone line:
- Green: Line is idle.
- Red (steady): Line is active or in use.
- Red (blinking): Line is on hold.
- Amber: Line is unregistered (cannot be used).
- Flashing Amber: The phone is not connected to the
network.
5. Softkey buttons
Press to perform the action shown directly above it on the screen
e.g. Redial.
6. Navigation button
Press up or down to scroll through menu items on the LCD
screen.
