• The system side BERT is not supported on partial timeslots. For the system side BERT, use full timeslots.
Configuring BERT for CESoPSN
Before You Begin
Before you run BERT test, you must configure card type and controller.
To run a BERT on T1/E1 interface for CESoPSN, perform the following tasks in global configuration mode.
enable
configure terminal
controller t1/e1 0/1/1
bert pattern 2^11 interval 5 direction line/system timeslots value speed
exit
To terminate a BERT test during the specified test period, use the no bert command.
Note
Verifying BERT Configuration for CESoPSN
Use the following command to verify the BERT configuration for CESoPSN on T1 interfaces:
Router# show controllers t1 0/4/32 brief
T1 0/4/32 is up
Applique type is NCS4200-48T1E1-CE
Cablelength is short 110
DS0 Bert enabled on the following timeslots : 1-2
Speed : 64 kpbs
DSX1 BERT test result: (running)
DSX1 BERT pattern : 2^15
DSX1 BERT direction : Line
DSX1 BERT sync : sync
DSX1 BERT sync count : 1
DSX1 BERT interval : 1
DSX1 BERT time remain : 00:00:55
DSX1 BERT total errs : 0
DSX1 BERT total k bits: 512
DSX1 BERT errors (last): 0
DSX1 BERT k bits (last): 512
Last clearing of BERT counters never
No alarms detected.
alarm-trigger is not set
Soaking time: 3, Clearance time: 10
AIS State:Clear LOS State:Clear LOF State:Clear
Framing is ESF, Line Code is B8ZS, Clock Source is Recovered Clock 32.
BER thresholds: SF = 10e-3 SD = 10e-6
Data in current interval (710 seconds elapsed):
39 Line Code Violations, 0 Path Code Violations
0 Slip Secs, 1 Fr Loss Secs, 1 Line Err Secs, 0 Degraded Mins
1 Errored Secs, 0 Bursty Err Secs, 1 Severely Err Secs, 0 Unavail Secs
0 Near-end path failures, 0 Far-end path failures, 1 SEF/AIS Secs
Data in Interval 1:
0 Line Code Violations, 0 Path Code Violations
0 Slip Secs, 0 Fr Loss Secs, 0 Line Err Secs, 0 Degraded Mins
0 Errored Secs, 0 Bursty Err Secs, 0 Severely Err Secs, 0 Unavail Secs
0 Near-end path failures, 0 Far-end path failures, 0 SEF/AIS Secs
48-Port T1/E1 CEM Interface Module Configuration Guide, Cisco IOS XE Fuji 16.7.x (Cisco NCS 4200 Series)
10
Configuring T1/E1 Interfaces on 48-Port T1/E1 Interface Module
Configuring BERT for CESoPSN
