Configuring DS1 Local Connet
The following section describes how to configure first segment for DS1 local connection:
enable
configure terminal
controller T1 0/5/0
framing unframed
clock source internal
linecode b8zs
cablelength short 110
cem-group 0 unframed
description TO_CE1_0/1/0
The following section describes how to configure second segment for DS1 local connection:
enable
configure terminal
controller T1 0/5/3
framing unframed
clock source recovered 0
linecode b8zs
cablelength short 110
cem-group 0 unframed
description TO_CE1_0/1/1
The following section describes how to create a DS1 local connection:
enable
configure terminal
connect ds1_connect CEM0/5/0 0 CEM0/5/3 0
Verifying DS1 Local Connect
Use the following commands to verify the DS1 local connection:
• show connection name—Displays information about the connection state and segment state.
Router#show connection name ds1_connect
Connection: 673 – ds1_connect
Current State: UP
Segment 1: CEM0/5/0 SATOP T1 0 up
Segment 2: CEM0/5/3 SATOP T1 0 up
Associated Commands
The following commands are used to configure pseudowire:
URLCommands
http://www.cisco.com/c/en/us/td/docs/ios-xml/ios/
interface/command/ir-cr-book/
ir-c1.html#wp2440628600
cem-group
48-Port T1/E1 CEM Interface Module Configuration Guide, Cisco IOS XE Fuji 16.7.x (Cisco NCS 4200 Series)
24
Overview of Circuit Emulation
Configuring DS1 Local Connet
