D14636.13 Profile C60-C40 and Codec C60-C40 Administrator Guide TC7.0, DECEMBER 2013. www.cisco.com — Copyright © 2010-2013 Cisco Systems, Inc. All rights reserved.
142
Cisco TelePresence System Codec C40/C60 and Profiles using C40/60 Administrator Guide
MULTIPOINT SUPPORT
• Four-way embedded SIP/H.323 MultiPoint, reference
MultiSite
• Cisco TelePresence Multiway support (requires Cisco
TelePresence Video Communication Server [Cisco VCS]
and Cisco TelePresence MCU)
• Ability to natively join multipoint conferences hosted on
Cisco Telepresence Multipoint Switch (CTMS)
MULTISITE FEATURES*
(embedeed multipoint)
• Four-way SIP/H.323 MultiSite. Resolution up to 720p30
(C60) / w576p30 (C40)
• Full individual audio and video transcoding
• Individual layouts in multisite continuous presence
(takes out selfview)
• H.323/SIP/VoIP in the same conference
• Support for Presentation (H.239/BFCP) from any
participant at resolutions up to WXGAp30 (C60) /
WXGAp30 (C40)
• Best Impression (automatic continuous presence
layouts)
• H.264, encryption, and dual stream from any site
• Dial in and dial out
• Additional telephone call (no license required)
• Conference rates up to 10 Mbps
PROTOCOLS
• H.323
• SIP
• ISDN (requires Cisco TelePresence ISDN Link)
EMBEDDED ENCRYPTION
• H.323/SIP point-to-point
• Standards-based: H.235 v3 and Advanced Encryption
Standard (AES)
• Automatic key generation and exchange
• Supported in Dual Stream
IP NETWORK FEATURES
• DNS lookup for service configuration
• Differentiated Services (QoS)
• IP adaptive bandwidth management (including flow
control)
• Auto gatekeeper discovery
• Dynamic playout and lip-sync buffering
• H.245 DTMF tones in H.323
• Date and time support via NTP
• Packet loss based downspeeding
• URI Dialing
• TCP/IP
• DHCP
• 802.1x Network authentication
• 802.1Q Virtual LAN
• 802.1p QoS and class of service
• ClearPath
• Medianet: Mediatrace and Metadata
IPV6 NETWORK SUPPORT
• Single call stack support for both H323 and SIP
• Dual-stack IPv4 and IPv6 for DHCP, SSH, HTTP, HTTPS,
DNS, DiffServ
• Support for both static and autoconfiguration (stateless
address autoconfiguration)
CISCO UNIFIED COMMUNICATIONS MANAgER
(requires Cisco UCM version 8.6 or later)
• Native registration with Cisco Unified Communications
Manager
• Basic Cisco Unified Communications Manager
provisioning
• Firmware upgrade from Cisco Unified Communications
Manager
• Cisco Discovery Protocol and DHCP option 150 support
• Basic telephony features such as hold, resume, transfer,
and corporate directory lookup
SECURITY FEATURES
• Management through HTTPS and SSH
• IP administration password
• Menu administration password
• Disable IP services
• Network settings protection
NETWORK INTERFACES
• One LAN/Ethernet (RJ-45) 10/100/1000 Mbit
• One LAN/Ethernet (RJ-45) interface to be used for the
Cisco TelePresence Touch for C-series user interface
device only
OTHER INTERFACES
• USB host for future usage (C60 only)
• USB device for future usage
• GPIO – General purpose input/output (C60 only)
PRECISIONHD 1080P CAMERA
• 1/3” CMOS
• 12 × zoom (C60)
• 12 × zoom / 4 × zoom (C40)
• +15°/-25° tilt, +/- 90° pan
• 43.5° vertical field of view
• 72° horizontal field of view
• Focus distance 0.3 m–infinity
• 1920 × 1080 pixels progressive @ 60fps
(12 × zoom version)
•
1920 × 1080 pixels progressive @ 30fps
(4 × zoom version)
•
Other formats supported (configurable through dip-
switch):
- 1920 × 1080@60 Hz (HDMI only)***
- 1920 × 1080@50 Hz (HDMI only)***
- 1920 × 1080@30 Hz
- 1920 × 1080@25 Hz
- 1280 × 720@60 Hz***
- 1280 × 720@50 Hz ***
- 1280 × 720@30 Hz
- 1280 × 720@25 Hz
• Automatic or manual focus/brightness/white balance
• Far-end camera control
• Daisy-chain support (Visca protocol camera)***
• Dual HDMI and HD-SDI outputs
• Upside-down mounting with automatic flipping of
SYSTEM MANAgEMENT
• Support for the Cisco TelePresence Management Suite
(Cisco TMS)
• Total management through embedded SNMP, Telnet,
SSH, XML, SOAP
• Remote software upload through web server, SCP,
HTTP, HTTPS
• One RS-232 for local control and diagnostics
• Remote control and on-screen menu system
DIRECTORY SERVICES
• Support for local directories (My Contacts)
• Corporate directory
• Unlimited entries using server directory supporting
LDAP and H.350 (requires Cisco TMS)
• Unlimited number for corporate directory (through
Cisco TMS)
• Received calls with date and time
• Placed calls with date and time
• Missed calls with date and time
POWER
• Auto-sensing power supply
• 100-120/200-240 VAC, 60/50 Hz
• 175 watts max for codec and main camera
OPERATINg TEMPERATURE AND HUMIDITY
• 0° C to 35° C (32° F to 95° F) ambient temperature
• 10% to 90% relative humidity (RH)
STORAgE AND TRANSPORT TEMPERATURE
• -20° C to 60° C (-4° F to 140° F) at RH 10–90% (non-
condensing)
DIMENSIONS
• Length: 17.4 in. / 44.2 cm
• Height: 1.7 in. / 4.4 cm
• Depth: 10.9 in. / 27.8 cm
• Weight: 8.8 lbs / 4 kg
* Requires option
** Multiwindow compositing not supported on the dual stream
*** Not supported on 4 x zoom camera
