D14636.13 Profile C60-C40 and Codec C60-C40 Administrator Guide TC7.0, DECEMBER 2013. www.cisco.com — Copyright © 2010-2013 Cisco Systems, Inc. All rights reserved.
141
Cisco TelePresence System Codec C40/C60 and Profiles using C40/60 Administrator Guide
Technical specifications
Codec C60/C40
UNIT DELIVERED COMPLETE WITH:
• Video conferencing codec, wireless remote control,
rack mounting rails (C60), rack mounting ears (C40),
LAN cable, power cable
BANDWIDTH
• H.323/SIP up to 6 Mbps point-to-point
FIREWALL TRAVERSAL
• Cisco TelePresence Expressway technology
• H.460.18, H.460.19 firewall traversal
• SIP ICE (Interactive Connectivity Establishment)
VIDEO STANDARDS
• H.261
• H.263
• H.263+
• H.264
VIDEO FEATURES
• Native 16:9 widescreen
• Advanced screen layouts
• Intelligent video management
• Local auto layout
• 7 embedded individual video compositors — 1 for every
output and 1 for every encoder (C60 only) **
VIDEO INPUTS (5 INPUTS (C60) / 4 INPUTS (C40))
Two HDMI inputs; supported formats:
• 1920 × 1080@60, 59.94 Hz (1080p60)
• 1920 × 1080@50 Hz (1080p50)
• 1920 × 1080@30, 29.97 Hz (1080p30)
• 1920 × 1080@25 Hz (1080p25)
• 1920 × 1080@24, 23.97 Hz (1080p24)
• 1280 × 720@60, 59.94 Hz (720p60)
• 1280 × 720@50 Hz (720p50)
• 720 × 480@60, 59.94 Hz (480p60)
• 640 × 480@60 Hz (480p60)
• 1600 × 1200@50, 60 Hz (UXGA)
• 1280 × 1024@60, 75 Hz (SXGA)
• 1024 × 768@60, 70, 75, 85 Hz (XGA)
• 800 × 600@56, 60, 72, 75, 85 Hz (SVGA)
• 1920 × 1200@50, 60 Hz (WUXGA)
• 1680 × 1050@60 Hz (WSXGA+)
• 1440 × 900@60 Hz (WXGA+)
• 1280 × 768@60 Hz (WXGA)
Two (C60), one (C40) × DVI-I inputs; supported formats:
Analog (VGA):
• 1920 × 1080@60 Hz (1080p60)
• 1280 × 720@60 Hz (720p60)
• 1600 × 1200@60 Hz (UXGA)
• 1280 × 1024@60, 75 Hz (SXGA)
• 1280 × 960@60 Hz
• 1024 × 768@60, 70, 75, 85 Hz (XGA)
• 1920 × 1200@50 Hz (WUXGA)
• 1680 × 1050@60 Hz (WSXGA+)
• 1440 × 900@60 Hz (WXGA+)
• 1280 × 800@60 Hz (WXGA)
• 1280 × 768@60 Hz (WXGA)
Analog (YPbPr):
• 1920 × 1080@60 Hz (1080p60)
• 1920 × 1080@50 Hz (1080p50)
• 1920 × 1080@30 Hz (1080p30)
• 1920 × 1080@25 Hz (1080p25)
• 1280 × 720@60 Hz (720p60)
• 1280 × 720@50 Hz (720p50)
• 1280 × 720@30 Hz (720p30)
• 720 × 576@50 Hz (576p50)
• 720 × 480@60 Hz (480p60)
Digital (DVI-D):
• Same as HDMI, ref. above.
One S-video/Composite input (BNC connector):
• PAL/NTSC
• Extended Display Identification Data (EDID)
VIDEO OUTPUTS (3 OUTPUTS (C60) /
2 OUTPUTS (C40))
O
ne HDMI output, one DVI-I output; supported formats:
• 1920 × 1080@60 Hz (1080p60)
• 1280 × 720@60 Hz (720p60)
• 1600 × 1200@60 Hz (UXGA)
• 1280 × 1024@60 Hz (SXGA)
• 1024 × 768@60 Hz (XGA)
• 800 × 600@60 Hz (SVGA)
• 640 × 480@60 Hz (VGA)
• 1920 × 1200@60Hz (WUXGA)
• 1360 × 768@60 Hz
• 1366 × 768@60 Hz
• 1280 × 768@60 Hz (WXGA)
One composite output (BNC connector) (C60 only):
• PAL/NTSC
• VESA Monitor Power Management
• Extended Display Identification Data (EDID)
LIVE VIDEO RESOLUTIONS (ENCODE/DECODE)
• 176 × 144@30 fps (QCIF)
• 352 × 288@30 fps (CIF)
• 512 × 288@30 fps (w288p)
• 576 × 448@30 fps (448p)
• 768 × 448@30 fps (w448p)
• 704 × 576@30 fps (4CIF)
• 1024 × 576@30 fps (w576p)
• 1280 × 720@30 fps (720p30)
• 1920 × 1080@30 fps (1080p30)*
• 640 × 480@30 fps (VGA)
• 800 × 600@30 fps (SVGA)
• 1024 × 768@30 fps (XGA)
• 1280 × 1024@30 fps (SXGA) (C60 only)
• 1280 × 768@30 fps (WXGA)
• 1440 × 900@30 fps (WXGA+)* (C60 only)
• 1680 × 1050@30 fps (WSXGA+)* (C60 only)
• 1600 × 1200@30 fps (UXGA)* (C60 only)
• 1920 × 1200@25fps (WUXGA)* (C60 only)
• 512 × 288@60 fps (w288p60)*
• 768 × 448@60 fps (w448p60)*
• 1024 × 576@60 fps (w576p60)*
• 1280 × 720@60 fps (720p60)*
• 720p30 from 768kbps
• 720p60 from 1152kbps*
• 1080p30 from 1472 kbps*
AUDIO STANDARDS
• G.711
• G.722
• G.722.1
• G.729AB
• 64 kbps and 128 kbps AAC-LD, mono and stereo
AUDIO FEATURES
• CD quality 20 kHz mono and stereo
• Four (C60) / Two (C40) separate acoustic echo
cancellers
• 4-port (C60) / 2-port (C40) audio mixer
• Automatic gain control (AGC)
• Automatic noise reduction
• Active lip synchronization
AUDIO INPUTS (7 INPUTS (C60), 5 INPUTS (C40))
• Four microphones (C60) / two microphones (C40), 48 V
phantom powered, XLR connector, each with separate
echo cancellers and noise reduction; all microphones
can be set for balanced line level
• Two RCA/Phono inputs, line level: Stereo PC input,
configurable to two RCA/Phono inputs, line level: Mono
auxiliary/DVD input
• One HDMI input, digital: stereo PC/DVD input
AUDIO OUTPUTS (3 OUTPUTS)
• Two RCA/Phono outputs, line level, stereo main audio,
configurable to S/PDIF or two RCA/Phono outputs, line
level, mono to recording device
• One HDMI output, digital, stereo main audio
DUAL STREAM
• H.239 (H.323) dual stream
• BFCP (SIP) dual stream
•
Support for resolutions up to 1080p30/WUXGA
(C60)/ WXGAp30 (C40), independent of main stream
resolution
* Requires option
** Multiwindow compositing not supported on the dual stream
*** Not supported on 4 x zoom camera
