Cisco UCS C210 M2 - Performance and System Tuning; Performance Parameters; System Tuning Information

Cisco UCS C210 M2 General-Purpose Rack-Mount Server
DETAILED VIEWS
5
Chassis Rear View
Figure 3 shows the external features of the rear panel.
Figure 3 Chassis Rear View
1 Power supply (up to 2) 5 Serial connector (DB9)
2 USB 2.0 connectors (2) 6 10/100/1000 Megabit Ethernet ports (2)
3 10/100 Ethernet management port (RJ-45) 7 Standard-profile PCIe card slots (five total)
4 Video connector (DB15 VGA)
