Cisco UCS C210 M2 General-Purpose Rack-Mount Server
TECHNICAL SPECIFICATIONS
59
TECHNICAL SPECIFICATIONS
Dimensions and Weight
Power Specifications
The general power specifications for the C210 M2 server are listed in Table 30.
Table 29 UCS C210 M2 Dimensions and Weight
1
1. The system weight given here is an estimate for a fully configured system and will vary depending on the
number of peripheral devices and power supplies.
Parameter Value
Height 3.45 in. (8.76 cm)
Width 17.39 in.(44.17 cm)
Depth 28.35 in. (72.01 cm)
Front Clearance 3 in. (7.62 cm)
Side Clearance 1 in. (2.54 cm)
Rear Clearance 6 in. (15.24 cm)
Weight
50.70 lbs (23 kg)
*
Table 30 UCS C210 M2 Power Specifications
Description Specification
AC input voltage 100 to 120 VAC nominal
200 to 240 VAC nominal
(Range: 90 to 264 VAC)
AC input frequency 50 to 60 Hz nominal (Range: 47 to 63 Hz)
Maximum AC input current 8 A at 100 VAC
Maximum AC inrush current 30 A peak sub-cycle duration
Maximum output power for each
power supply
650 W
Power supply output voltage Main power: 12 VDC
Standby Power: 5 VDC
Power supply efficiency 92% Peak, complies with 80Plus Gold Standard
