Cisco UCS C220 M3 Configuration Guide

© 2014 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public. Page 11 of 33
Management Interfaces
You can use a web-based GUI or Secure Shell (SSH)–based command-line interface (CLI) to access, configure,
administer, and monitor the server. Almost all tasks can be performed in either interface, and the results of tasks
performed in one interface are displayed in the other. However, you cannot do the following:
●
Use the Cisco IMC GUI to invoke the Cisco IMC CLI
●
View a command that has been invoked through the Cisco IMC CLI in the Cisco IMC GUI
●
Generate Cisco IMC CLI output from the Cisco IMC GUI
Tasks You Can Perform in Cisco IMC
You can use the Cisco IMC to perform the following server management tasks:
●
Power on, power off, power cycle, reset, and shut down the server
●
Toggle the locator LED
●
Configure the server boot order
●
View server properties and sensors
●
Manage remote presence
●
Create and manage local user accounts and enable remote-user authentication through Microsoft Active
Directory
●
Configure network-related settings, including network interface card (NIC) properties, IPv4, VLANs, and
network security
●
Configure communication services, including HTTP, SSH, and Intelligent Platform Management Interface
(IPMI) over LAN
●
Manage certificates
●
Configure platform event filters
●
Update Cisco IMC firmware
●
Monitor faults, alarms, and server status
Creating Virtual Drives from Unused Physical Disks
A drive group is a group of physical drives. These drives are managed in partitions known as virtual drives.
A virtual drive is a partition in a drive group that is composed of contiguous data segments on the drives. A virtual
drive can consist of an entire drive group, multiple drive groups, an entire drive group plus parts of other drive
groups, a part of a drive group, parts of more than one drive group, or a combination of any two of these options.
Creating a RAID Volume Based on a Single Drive Group: RAID 0, 1, 5, and 6
Follow the steps presented here to create RAID volumes (virtual drives) from Cisco IMC.

Cisco UCS C220 M3 Specifications

General

Tcase	70 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor cache	10 MB
Processor cores	4
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor codename	Sandy Bridge EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	52.5 x 45.0 mm
Processor front side bus	- MHz
Processor boost frequency	2.50 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Graphics & IMC lithography	32 nm
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	24
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	750 GB
HDD size	2.5 \
HDD interface	-
Total storage capacity	500 GB
Compatible memory cards	SD
Maximum storage capacity	- TB
Memory slots	16
Internal memory	32 GB
Memory clock speed	1866 MHz
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Chassis type	Rack (1U)
Power supply	450 W
Safety	UL 60950-1 No. 21CFR1040, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, GB4943 2001
Certification	47CFR Part 15 (CFR 47), AS/NZS CISPR22, CISPR2 2, EN55022, ICES003, VCCI, EN61000-3-2, EN61000-3-3, KN22, CNS13438, EN55024, CISPR24, EN300386, KN24
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
PCI Express slots version	3.0
Processor ARK ID	64588
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	724 mm
Width	430 mm
Height	43.2 mm
