Cisco UCS C220 M4 Service Manual

C-13
Cisco UCS C220 M4 Server Installation and Service Guide
OL-32473-01
Appendix C RAID Controller Considerations
Embedded SATA RAID Controllers
Embedded SATA RAID Controller Considerations
Note the following considerations:
• The default setting for this embedded controller hub is SATA RAID 0, 1, and 10 support for up to
eight SATA drives (in two groups of four drives).
• You can upgrade to SATA RAID 0, 1, 5, 10 support for up to eight SATA drives (in two groups of
four drives) by installing a RAID 5 key module on the motherboard. See Installing a Software RAID
5 Key Module for Embedded RAID 5 Support, page C-13.
• When you order the server with this embedded controller, the controller is enabled in the BIOS.
Instructions for enabling the controller are included for the case in which a server is reset to defaults
(Disabled). See Enabling the Embedded SATA RAID Controller in the BIOS, page C-13.
• You cannot downgrade from using a hardware RAID controller card to using the software RAID
embedded controller (see RAID Controller Migration, page C-7).
Caution Data migration from software RAID (embedded RAID) to hardware RAID (a controller card) is not
supported and could result in data loss. Migrations from software RAID to hardware RAID are supported
only before there is data on the drives, or when there are no drives in the server (see RAID Controller
Migration, page C-7).
• The required drivers for this controller are already installed and ready to use with the LSI SWRAID
Configuration Utility. However, if you will use this controller with Windows or Linux, you must
download and install additional drivers for those operating systems. See Installing LSI MegaSR
Drivers For Windows and Linux, page C-16.
Installing a Software RAID 5 Key Module for Embedded RAID 5 Support
The software RAID 5 key module contains a chip on a small circuit board. This module attaches to a
two-pin motherboard header. This chip upgrades support to add embedded SATA RAID 5 support.
To install a RAID 5 key module, see Installing a Software RAID 5 Key Module for Embedded RAID 5
Support, page C-13.
Enabling the Embedded SATA RAID Controller in the BIOS
Note The default setting in the BIOS for the embedded controller is disabled.
When you enable this controller, both the primary (SATA) and secondary (sSATA) controllers are
enabled.

Cisco UCS C220 M4 Specifications

General

Tcase	78.9 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor code	SR1YA
Processor cache	25 MB
Processor cores	10
System bus rate	9.6 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor threads	20
Processor codename	Haswell
Motherboard chipset	Intel C610
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	3 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	105 W
Compatible processor series	Intel® Xeon®
Supported processor sockets	LGA 2011-v3 (Socket R)
Number of processors installed	2
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	68 GB/s
Maximum internal memory supported by processor	768 GB
HDD size	- \
RAID levels	0, 1, 5, 6, 10, 50, 60, JBOD
HDD interface	-
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Memory slots	24
Internal memory	16 GB
Memory clock speed	2133 MHz
Maximum internal memory	384 GB
Maximum graphics card memory	8 MB
Graphics card	G200e
Graphics card family	Matrox
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
PCI Express slots version	3.0
Processor ARK ID	81705
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Power supply	770 W
Power supply input frequency	50 - 60 Hz
Chassis type	Rack (1U)
Trusted Platform Module (TPM) version	1.2
Compatible operating systems	Microsoft Windows Server 2012 R2 Microsoft Windows Server 2012 Microsoft Windows Server 2008 R2 Red Hat Enterprise Linux Novell SUSE Linux Enterprise Server Oracle Linux (Unbreakable Enterprise Kernel (UEK)) Oracle Solaris Ubuntu Server CentOS

Weight and Dimensions

Depth	756 mm
Width	430 mm
Height	43.2 mm
