Cisco UCS C220 M4 Service Manual

1-6
Cisco UCS C220 M4 Server Installation and Service Guide
OL-32473-01
Chapter 1 Overview
Summary of Server Features
Summary of Server Features
Table 1-1 lists the features of the server.
.
Table 1-1 Cisco UCS C220 M4 Server Features
Feature Description
Chassis One rack-unit (1RU) chassis.
Processors Up to two Intel Xeon E5-2600 v3 Series processors.
Memory 24 DDR4 DIMM
1
sockets on the motherboard (12 each CPU).
Multi-bit error
protection
Multi-bit error protection is supported.
Baseboard
management
BMC, running Cisco Integrated Management Controller (Cisco IMC) firmware.
Depending on your Cisco IMC settings, Cisco IMC can be accessed through the
1-Gb dedicated management port, the 1-Gb Ethernet LOM ports, or a Cisco virtual
interface card.
Network and
management I/O
Supported connectors:
• One 1-Gb Ethernet dedicated management port
• Two 1-Gb BASE-T Ethernet LAN ports
• One RS-232 serial port (RJ-45 connector)
• One 15-pin VGA
2
connector
• Two USB
3
3.0 connectors
• One front-panel KVM connector that is used with the KVM cable, which
provides two USB 2.0, one VGA, and one serial (DB-9) connector.
Modular LOM Dedicated socket that can be used to add an mLOM card for additional rear-panel
connectivity (up to four 1-Gb or 10-Gb Ethernet ports).
WoL 1-Gb BASE-T Ethernet LAN ports support the wake-on-LAN (WoL) standard.
Power Two power supplies:
• AC power supplies 770 W AC each.
Do not mix power supply types or wattages in the server.
Redundant as 1+1. See Power Specifications, page A-3.
ACPI The advanced configuration and power interface (ACPI) 4.0 standard is supported.
Cooling Six hot-swappable fan modules for front-to-rear cooling.
PCIe I/O Two horizontal PCIe
4
expansion slots on two risers (single riser assembly).
See Replacing a PCIe Card, page 3-38 for specifications of the slots.
InfiniBand The bus slots in this server support the InfiniBand architecture.
Storage Drives are installed into front-panel drive bays that provide hot-swappable access
for SAS/SATA drives. The server is orderable in two different versions, each with
one of two different front panel/backplane configurations
• Cisco UCS C220 M4—Small form-factor (SFF) drives, with eight-drive
backplane. Holds up to eight 2.5-inch hard drives or solid state drives.
• Cisco UCS C220 M4—Large form factor (LFF) drives, with four-drive
backplane. Holds up to four 3.5-inch hard drives.

Cisco UCS C220 M4 Specifications

General

Tcase	78.9 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor code	SR1YA
Processor cache	25 MB
Processor cores	10
System bus rate	9.6 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor threads	20
Processor codename	Haswell
Motherboard chipset	Intel C610
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	3 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	105 W
Compatible processor series	Intel® Xeon®
Supported processor sockets	LGA 2011-v3 (Socket R)
Number of processors installed	2
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	68 GB/s
Maximum internal memory supported by processor	768 GB
HDD size	- \
RAID levels	0, 1, 5, 6, 10, 50, 60, JBOD
HDD interface	-
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Memory slots	24
Internal memory	16 GB
Memory clock speed	2133 MHz
Maximum internal memory	384 GB
Maximum graphics card memory	8 MB
Graphics card	G200e
Graphics card family	Matrox
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
PCI Express slots version	3.0
Processor ARK ID	81705
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Power supply	770 W
Power supply input frequency	50 - 60 Hz
Chassis type	Rack (1U)
Trusted Platform Module (TPM) version	1.2
Compatible operating systems	Microsoft Windows Server 2012 R2 Microsoft Windows Server 2012 Microsoft Windows Server 2008 R2 Red Hat Enterprise Linux Novell SUSE Linux Enterprise Server Oracle Linux (Unbreakable Enterprise Kernel (UEK)) Oracle Solaris Ubuntu Server CentOS

Weight and Dimensions

Depth	756 mm
Width	430 mm
Height	43.2 mm
