Cisco UCS C220 M4

3-32
Cisco UCS C220 M4 Server Installation and Service Guide
OL-32473-01
Chapter 3 Maintaining the Server
Installing or Replacing Server Components
Figure 3-19 TMM on Modular RAID Controller Card
1 TMM on modular RAID card 5 Side view, guide peg
2 Securing bracket clips 6 Side view, socket on modular RAID card
3 Guide pegs on bracket protruding through
guide holes on TMM
7 Side view, connector on underside of TMM
4 SCPM cable connector on TMM 8 Side view, securing clips
304945
4
1
65 7
3
2
8
1 1
2
