CONFIGURING the SERVER
Approved Configurations
(1) 1-CPU Configurations
Mezzanine cards are not supported for 1-CPU configurations, Therefore, only the following RAID
controllers are supported for single-CPU configurations:
■ Embedded RAID (on motherboard)
■ LSI MegaRAID SAS 9266-8i
■ LSI MegaRAID 9266CV-8i
(2) 2-CPU Configurations
Select an embedded RAID option from Table 5, one mezzanine RAID controller from Table 6 on
page 18, or one PCIe RAID controller from Table 7 on page 18. You may also select an
appropriate optional RAID configuration listed in Table 7 on page 18.
Caveats
■ The mezzanine controller is not available for 1-CPU configurations.
■ If you choose embedded RAID or a mezzanine card RAID controller, all five of the PCIe card
slots are still available for adding optional PCIe cards.
■ The optional PCIe RAID controllers are all half-height PCIe cards. If you choose one of these
cards, four PCIe card slots will be available for adding an optional PCIe card.
■ Note that only a single Cisco UCS P81E Virtual Interface Card (VIC) card (a full-height PCIe
card) is supported and it must be installed in the full-length, full-height PCIe slot (slot 1) on
riser 1. So take this into account when populating RAID controller cards.
■ You can choose only one RAID controller (embedded RAID, mezzanine RAID, or a plug-in PCIe
RAID controller).
■ You can choose an optional RAID configuration (RAID 0, 1, 5, 6, or 10), which is
preconfigured at the factory. The RAID level you choose must be an available RAID choice for
the controller selected. RAID levels 50 and 60 are supported, although they are not available
as configuration options.
■ RAID support is dependent on the backplane:
— A system with 16-drive backplane with no SAS expander:
• Supports up to 8 drives with ROM5 and ROM55 embedded RAID upgrades
• Supports up to 8 drives with mezzanine cards
• Supports up to 8 drives for each 9266-8i and 9266CV-8i controller
• Supports up to 4 SATA-only drives if no ROM upgrade, mezzanine card, or plug-in
PCIe card chosen
— A system with 24-drive backplane with SAS expander:
• Does not support ROM5 and ROM55 embedded RAID upgrades
• Supports up to 16 drives with mezzanine cards

Cisco UCS C240 M3 Specifications

General

Processor cores	8
Processor model	E5-2600
Processor frequency	2.7 GHz
Number of processors installed	2
HDD size	2.5 \
RAID support	Yes
HDD interface	-
Optical drive type	No
Total storage capacity	300 GB
Maximum storage capacity	- TB
Number of HDDs installed	16
Memory slots	24
Internal memory	96 GB
Memory clock speed	1866 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express x8 slots	3
Chassis type	Rack (2U)
Power supply	650 W
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Operating temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	712 mm
Width	445 mm
Height	87 mm
