Solution Design
22
System Hardware and Software Specifications
Software Versions
Layer
Component
Version or Release
Storage (Chassis) UCS S3260
Chassis Management Controller
4.0(1c)
Shared Adapter
4.0(1c)
Compute (Server Nodes) UCS S3X60
M5
BIOS
S3260M5.4.0.1b
CIMC Controller
4.0(1a)
Compute (Rack Server) C220 M5S
BIOS
C220M5.4.0.1c
CIMC Controller
4.0(1a)
Network 6332 Fabric Interconnect
UCS Manager
4.0(1a)
Kernel
5.0(3)N2(4.01a)
System
5.0(3)N2(4.01a)
Network Nexus 9332PQ
BIOS
07.51
NXOS
7.0(3)I4(8b)
Software
Red Hat Enterprise Linux Server
7.5 (x86_64)
Cloudian HyperStore
7.1.2
Hardware Requirements and Bill of Materials
Component
Model
Quantity
Comments
Cloudian Storage
Nodes
Cisco UCS S3260
M5 Chassis
3
 2 x UCS S3X60 M5 Server Nodes per Chassis
(Total = 6nodes)
 Per Server Node
 2 x Intel Xeon Silver 4114 (2.2GHz/10cores),
192 GB RAM
 Cisco 12G RAID Controller
 2 x SSD for OS
 28 x 10TB HDDs for Data,
 1 NVMe for metadata per node.
 Dual-port 40 Gbps VIC

Cisco UCS S3260 M5 Specifications

General

Processor	Intel Xeon Scalable processors
Memory	Up to 3TB per node (24 DIMM slots per node)
Storage	Up to 600 TB
Drive Bays	60 x 3.5-inch or 2.5-inch drive bays
Form Factor	4U
Management	Cisco Integrated Management Controller (IMC)
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
