Cisco UCS S3260 Service Manual

E-21
Cisco UCS S3260 Storage Server Chassis Installation and Service Guide
Appendix E Upgrading to Cisco UCS S3260 System With S3260 M5 Server Nodes
Older Migration and Upgrade Procedures
Note The BMC reboots after resetting to defaults. Watch for the prompt to press F8 when the server
reboots in the next step.
Step 13 When prompted, press F8 to enter the Cisco IMC Configuration Utility again.
Step 14 Set a new Cisco IMC password when prompted.
Step 15 Configure the management, CMC, and BMC IP addresses for the system.
Note If you use a DHCP server and you already have QSFP cables attached to the SIOC, the management IP
address and network settings are already filled in. If you disable DHCP, you must set your own static
management IP address and network settings.
Step 16 This step only for setting static IPs (DHCP disabled)—Set the CMC and BMC internal IP addresses
by using the Cisco IMC interface, as described in Setting Static CMC and BMC Internal IP Addresses,
page 2-18.
Step 17 Use the Cisco IMC (GUI or CLI) to define hard drive zoning, which maps the hard drives to individual
server nodes:
• Using the Cisco IMC GUI:
a. Use the IP address of the CMC in either SIOC to log in to the Cisco IMC management software.
b. Navigate to the following tab:
Chassis > Inventory > Dynamic Storage > Zoning
c. Select the drives and then assign them to Server1 or Server2.
• Using the Cisco IMC CLI, enter the following commands with your choices:
Server# scope chassis
Server /chassis# scope dynamic-storage
Server /chassis/dynamic-storage# assign-drive <server ID> <drive-slotid-list>
For example:
Server# scope chassis
Server /chassis # scope dynamic-storage
svbu-huu-sanity-col2-1-vcmc /chassis/dynamic-storage # assign-drive server2 27
Are you sure you want to assign drives 27 to server2
Enter 'yes' to confirm -> yes
assign-drive operation successful.
Step 18 If you want to add a second server node and SIOC to the system, continue with Installing a Second Server
Node or SIOC to the S3260 System With M4 Server Nodes, page E-28.

Cisco UCS S3260 Specifications

General

Drive Bays	Up to 56
Maximum Storage Capacity	Up to 600 TB
Power Supply	Up to 4 hot-plug power supplies
Product Type	Storage Server Chassis
Supported Drives	SAS, SATA
Processors	Up to two Intel Xeon Scalable processors
Memory	Up to 1.5 TB DDR4 RAM
Power Supplies	Redundant 80+ Platinum power supplies
Total Drive Bays	56
Management	Cisco UCS Manager
Compatibility	Cisco UCS system
Form Factor	4U rack
