3-15
Cisco UCS S3260 Storage Server Chassis Installation and Service Guide
Chapter 3 Maintaining the System
Installing or Replacing System Components
Installing or Replacing System Components
Warning
Blank faceplates and cover panels serve three important functions: they prevent exposure to
hazardous voltages and currents inside the chassis; they contain electromagnetic interference
(EMI) that might disrupt other equipment; and they direct the flow of cooling air through the
chassis. Do not operate the system unless all cards, faceplates, front covers, and rear covers are
in place.
Statement 1029
Caution This system weighs approximately 190 pounds (86 kilograms) when fully loaded with components. We
recommend that you use a mechanical lift when lifting the system. Attempting this procedure alone
could result in personal injury or equipment damage. Consider temporarily removing components such
as hard drives while you move the system.
• Replacing Hard Drives or Solid State Drives, page 3-16
–
Replacing HDDs or SSDs in the Internal Drive Compartment, page 3-18
–
Replacing Hard Drives in the Optional Disk Expansion Tray, page 3-21
–
Replacing SAS/SATA Solid State Drives in the Rear Panel Bays, page 3-23
• Replacing Fan Modules, page 3-25
• Replacing a Server Node, page 3-26
• Replacing a Disk Expansion Tray, page 3-27
• Replacing a System I/O Controller (SIOC), page 3-28
• Replacing a Power Supply, page 3-33
• Replacing DIMMs Inside a Server Node, page 3-36
• Replacing CPUs and Heatsinks Inside a Server Node, page 3-36
• Replacing a Storage Controller Card Inside the Server Node, page 3-36
• Replacing an SSD Inside the Server Node (C3X60 M4 or S3260 M5 Only), page 3-36
• Replacing an RTC Battery Inside the Server Node, page 3-36
• Replacing an Internal USB Drive Inside the Server Node (C3X60 M3 Only), page 3-36
• Installing a Trusted Platform Module (TPM) Inside the Server Node, page 3-37
• Replacing an I/O Expander (C3X60 M4 or S3260 M5 Server Nodes Only), page 3-37
• Replacing a PCIe Card Inside the I/O Expander (C3X60 M4 or S3260 M5 Server Nodes Only), page 3-37
• Replacing a Storage Controller Card Inside the I/O Expander (C3X60 M4 Server Nodes Only), page 3-37
• Replacing an NVMe SSD Inside the I/O Expander (C3X60 M4 or S3260 M5 Server Nodes Only), page 3-37
• Replacing an RTC Battery Inside the S3260 SIOC, page 3-38
• Replacing a PCIe Adapter Card Inside the S3260 SIOC (Version 03 SIOC Only), page 3-40
• Replacing an NVMe SSD Inside the S3260 SIOC (Version 03 SIOC Only), page 3-42
• Replacing an S3260 Chassis, page 3-47
• Service Headers on the Server Node Board, page 3-49
