50-2
Cisco Unified Communications Manager Bulk Administration Guide
OL-24965-01
Chapter 50 Inserting Gateways
Creating CSV Data Files for Cisco VG200 Gateways
Procedure
Step 1 To open the BAT spreadsheet, locate and double-click BAT.xlt file
Step 2 When prompted, click Enable Macros to use the spreadsheet capabilities.
Step 3 Click the VG200 T1-Pri T1-Cas E1-Pri FXSFXO tab.
Step 4 For T1 CAS endpoints only, scroll to the right until you see the Number of Port Identifiers field. Enter
the number of port identifiers that you want to add for each Cisco VG200 gateway. If you want only one
port identifier, skip this step.
Step 5 In each row, provide the information for the following fields:
• MGCP Domain Name—Enter a name, from 1 to 64 characters that identifies the gateway. Use the
Domain Name System (DNS) host name if it is configured to resolve correctly; otherwise, use the
host name as defined on the Cisco MGCP gateway.
The host name must match exactly the host name that is configured on the Cisco IOS gateway. For
example, if the host name is configured on the gateway to resolve to vg200-1 and the IP domain
name is not configured, enter the host name in this field (in this case, vg200-1). If the host name is
configured on the gateway as vg200-1 and the IP domain name is configured on the gateway as
cisco.com, enter vg200-1.cisco.com in this field.
• MGCP Description—Enter a description, up to 100 characters for the gateway. Use a specific
description that helps you locate the gateway.
• Port Description—Enter a description for port 1, up to 50 characters. Use a description to help
identify the port in a list of ports. This applies to the description field for port 2 through port 4.
• Port Directory Number—Enter the directory number, up to 24 numerals and special characters, for
this port. This applies to the directory number field for port 2 through port 4.
Note Port 1 Directory Number and Partition fields are required for FXS ports only. For FXO ports,
leave these fields blank.
• Slot—Enter the slot number that you are trying to configure. For VG200, it is always 1.
• Subunit—Enter an integer for the subunit value
• Port Number—Enter an integer for the Port Number.
Note For T1 CAS only, the ports that you specify here must be the same ports that you specified in
the VG200 template. In the CSV data file, you can specify none, some, or all ports that were
configured in the template. Do not configure any ports in the CSV data file that were not also
configured in the template, or an error will result when you attempt to insert the BAT VG200
template and the CSV file.
For example, if you configured ports 1,2,3, and 4 in the template, you could configure none of
the ports, or ports 1, 2, 3, and 4, or only ports 1 and 2 in the CSV file, and the insertion would
be accepted. But if you configured ports 5 and 6 in the CSV file when they are not configured in
the template, you will receive an insertion error in BAT.
Step 6 To transfer the data from the BAT Excel spreadsheet into a CSV file, click Export to BAT Format.
The system saves the file to C:\XLSDataFiles (or to your choice of another existing folder) as
VG200Gateways#timestamp.txt
