Figure 3: PS and Middle Side Mounting
The screw slots in the brackets are spaced to line up with every second pair of screw holes in the rack. When the correct
screw holes are used, the small, threaded holes in the brackets line up with unused screw holes in the rack. If the small
holes do not line up with the rack holes, you must raise or lower the brackets to the next rack hole.
The following images represent rack mounting for the Cisco VG420 Voice Gateway:
Installing the Cisco VG420 Voice Gateway
6
Installing the Cisco VG420 Voice Gateway
Mounting the Voice Gateway in Rack
