Cisco 2900 Series and 3900 Series Hardware Installation Guide
OL-18712-03
Chapter 5 Installing and Upgrading Internal Modules and FRUs
Locating Internal Modules
Figure 5-6 Module Locations in Cisco 3925 and Cisco 3945 Router
1 PVDM3 0 2 PVDM3 1
3 PVDM3 2 4 PVDM3 3
5 DIMM 0 socket 6 DIMM 1 socket
7 ISM
250955
1
7
2 3 654
