Cisco 7600 Series Router Supervisor Engine and Route Switch Processor Guide
OL-10100-11
Chapter 2 Route Switch Processors and Supervisor Engines
Overview
Table 2-1 lists the RSP and supervisor engine configurations supported on Cisco 7600 series routers.
Specific combinations of processors and modules may not be supported in your chassis. See the release
notes for your software version for information about supported combinations.
Table 2-1 Route Switch Processor and Supervisor Engine Configurations
Product Number Description
Route Switch Processor 720
RSP720-3C-10GE • Two 10 Gigabit Ethernet (10GE) uplink ports support 10-Gbps X2
modules
• Three Gigabit Ethernet (1GE) uplink ports: two ports support
1-Gbps small form-factor pluggable (SFP) module; one port
supports 10/100/1000-Mbps RJ-45 connector
Note Use Category 5 Shielded Twisted Pair cable at the port that
supports the10/100/1000-Mbps RJ-45 connector.
• Integrated 720-Gbps switch fabric
• PFC3C and MSFC4 with 512-MB bootdisk, 4-MB NVRAM,
4-MB ROMmon, and several DRAM options:
–
Route processor (RP): 1- to 4-GB DRAM (default 1 GB)
–
Switch processor (SP): 1- to 2-GB DRAM (default 1 GB)
• One CompactFlash Type II slot (512 MB) on front panel and two
internal CompactFlash (512 MB each for RP and SP; you can
optionally increase external compact flash and each internal
CompactFlash to 1 GB)
• Requires larger power supplies and a high-speed fan tray
• QoS port architecture, 10GE ports (Rx/Tx): 8q8t/1p7q8t (CoS)
• QoS port architecture, 1GE ports (Rx/Tx): 2q8t/1p3q8t
