B-10
Cisco 7600 Series Router Supervisor Engine and Route Switch Processor Guide
OL-10100-11
Appendix B Cable and Connector Specifications
Console Port Cabling Specifications and Pinouts
Console Port Cabling Specifications and Pinouts
The console port, which is located on the front panel of the supervisor engine or route switch processor,
provides access to the Cisco 7600 router. The following sections provide information about the console
port cabling specifications and the port’s signals and pinouts.
Console Port Cabling Specifications, page B-10
Console Port Signals and Pinouts, page B-11
Console Port Mode 2 Signaling and Pinouts (Sup2 Only), page B-13
Console Port Cabling Specifications
Table B-9 lists the maximum transmission distances for console port cables. See the “Console Port
Signals and Pinouts” section on page B-11 for console port and cable pinout information.
The accessories kit that is shipped with your router contains the necessary cable and adapters to connect
a terminal or modem to the front-panel console port.
Table B-8 Gigabit Ethernet Maximum Transmission Distances
GBIC
Wavelength
(nm)
Fiber Type
(MHz km)
Core Size
1
(micron)
1. Core size refers to the core diameter. The cladding diameter is usually 25 microns.
Modal Bandwidth
(MHz km) Cable Distance
2
2. Cable distances are based on fiber loss.
SX
3
3. MMF only.
850 MMF 62
62
50
50
160
200
400
500
722 ft (220 m)
902 ft (275 m)
1640 ft (500 m)
1804 ft (550 m)
LX/LH 1300 MMF
4
4. Patch cord required.
62
50
50
500
400
500
1804 ft (550 m)
1804 ft (550 m)
1804 ft (550 m)
SMF (LX/LH) 9/10 6.2 mi (10 km)
ZX
5
5. A maximum of 24 1000BASE-ZX GBICs is allowed for each system to comply with FCC Class A regulations.
1550 SMF
6
6. Dispersion-shifted single-mode fiber-optic cable.
9/10
8
43.5 mi (70 km)
7
62.1 mi (100 km)
7. The minimum link distance for ZX GBICs is 6.2 miles (10 km) with an 8-dB attenuator installed at each end of the link.
Without attenuators, the minimum link distance is 24.9 miles (40 km).
Table B-9 EIA/TIA-232 Transmission Speed Versus Distance
Rate (bps) Distance (feet) Distance (meters)
2400 200 60
4800 100 30
9600 50 15
