4-2
Cisco 7600 Series Router Supervisor Engine and Route Switch Processor Guide
OL-10100-11
Chapter 4 Troubleshooting Route Switch Processors and Supervisor Engines
Chassis and Supervisor Slot Installation
Chassis and Supervisor Slot Installation
Table 4-1 lists the chassis and their slots where the supervisors can be installed.
Table 4-1 Chassis and Supervisor Slot Installation
RSP720-1GE Supported Hardware and Features
The RSP720 supports the following Cisco 7600 chassis, line cards and modules:
• Supported on all Cisco 7600 routers (including enhanced chassis) except the Cisco 7603. At present
7603 is discontinued and only 7603S is shipped.
• SPA interface processors (SIPs) and their shared port adapters (SPAs): 7600-SIP-600,
7600-SIP-400, and 7600-SIP-200.
• Enhanced FlexWAN module (WS-X6582-2PA).
• Ethernet services modules: 2-port 10 GE line card (7600-ESM-2X10GE) and 20-port 1 GE line card
(7600-ESM-20X1GE).
• All boards in the ES+ line cards family.
• Distributed Forwarding Cards: DFC3C, DFC3CXL, DFC3B, DFC3BXL
• LAN cards.
RSP720-1GE Unsupported Hardware and Features
These hardware and features are not supported by the RSP720:
• Unsupported chassis: Cisco 7603.
• Unsupported modules: Optical Service Modules (OSMs), FlexWAN module.
Chassis Designated Supervisor Slots
7603S 1, 2
7604 1, 2
7606 5, 6
7606S 5, 6
7609 5, 6
7609S 5, 6
7613 7, 8
