2-6
Cisco 7600 Series Router Supervisor Engine and Route Switch Processor Guide
OL-10100-11
Chapter 2 Route Switch Processors and Supervisor Engines
Overview
RSP720-3CXL-GE • Two Gigabit Ethernet uplink ports: port 1 supports a 1-Gbps SFP
module; port 2 is configurable with either a 1-Gbps SFP module
or a 10/100/1000-Mbps RJ-45 connector
• Integrated 720-Gbps switch fabric
• PFC3CXL (high-capacity) and MSFC4 with 512-MB bootdisk
4-MB NVRAM, 4-MB ROMmon, and several DRAM options:
– Route processor (RP): 1- to 4-GB DRAM (default 2 GB)
– Switch processor (SP): 1- to 2-GB DRAM (default 1GB)
• Two CompactFlash Type II slots on front panel (512 MB default
with option to 1 GB) and two internal CompactFlash slots (one
each for RP and SP, 512 MB default for each)
• Requires larger power supplies and a high-speed fan tray
• QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t
Supervisor Engine 720
WS-SUP720 • Two Gigabit Ethernet uplink ports: port 1 supports a 1-Gbps SFP
module; port 2 is configurable with either a 1-Gbps SFP module
or a 10/100/1000-Mbps RJ-45 connector
• Integrated 720-Gbps switch fabric
• PFC3A and MSFC3 with 2-MB NVRAM, 512-MB DRAM, and
64-MB bootflash (see note below)
• Two CompactFlash Type II slots
• Requires larger power supplies and a high-speed fan tray
• QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t
Note Cisco IOS Release 12.2SXF is the last release in which the
Sup720 with PFC3A is supported.
WS-SUP720-3B
• Two Gigabit Ethernet uplink ports: port 1 supports a 1-Gbps SFP
module; port 2 is configurable with either a 1-Gbps SFP module
or a 10/100/1000-Mbps RJ-45 connector
• Integrated 720-Gbps switch fabric
• PFC3B and MSFC3 with 2-MB NVRAM, 512-MB DRAM, and
64-MB bootflash (see note below)
• Two CompactFlash Type II slots
• Requires larger power supplies and a high-speed fan tray
• QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t
Note To run Release SRE/15.0(1)S, SUP720 requires a minimum
of 1 GB DRAM.
Table 2-1 Route Switch Processor and Supervisor Engine Configurations (continued)
Product Number Description
