2-18
Cisco 7600 Series Router Supervisor Engine and Route Switch Processor Guide
OL-10100-11
Chapter 2 Route Switch Processors and Supervisor Engines
Supervisor Engine 2T
Table 2-5 shows the QoS features and scalability for Supervisor Engine 2T.
Table 2-5 QoS Features and Scalability
MPLS MPLS in hardware to enable
use of Layer 3 VPNs and
EoMPLS tunneling. Up to
8192 VRFs with a total of up
to 256K
1
forwarding entries
per system.
MPLS in hardware to enable
use of Layer 3 VPNs and
EoMPLS tunneling. Up to
8192 VRFs with a total of up
to 1024K forwarding entries
per system.
VLAN 4K 4K
Bridge domains 16k 16k
VPLS In hardware (Up to 390
Mpps**)
In hardware (Up to 390
Mpps**)
GRE In hardware (Up to 390
Mpps**)
In hardware (Up to 390
Mpps**)
NAT Hardware assisted Hardware assisted
MAC entries 128k 128k
Routes 256K(IPv4)
128K (IPv6)
1024K (IPv4)
512K (IPv6)
Netflow entries 512K 1024K
Multicast routes 128K (IPv4)
128K (IPv6)
128K (IPv4)
128K (IPv6)
1. 1K=1024.
Name VS-S2T-10G VS-S2T-10G-XL
Feature VS-S2T-10G VS-S2T-10G-XL
Layer-3 classification and
marking access control
entries (ACEs)
64K shared for QOS /
Security
256K shared for
QOS/Security
Aggregate traffic
rate-limiting policers
16348 16348
Flow-based rate-limiting
method; number of rates
Per source address,
destination address, or full
flow; 64 rates
Per source address,
destination address, or full
flow; 64 rates
Layer 2 rate limiters 20 ingress/6 egress 20 ingress/6 egress
MAC ACLs featuring
per-port/per VLAN
granularity
Yes Yes
Distributed policers Yes Yes
Shared uFlow policers Yes Yes
Egress uFlow policers Yes Yes
