Cisco WS-SUP720-3B - Supervisor Engine 720 User Manual

B-7
Cisco 7600 Series Router Supervisor Engine and Route Switch Processor Guide
OL-10100-11
Appendix B Cable and Connector Specifications
Uplink Port Transceiver Modules
Table B-5 lists the cabling specifications for the 1GE uplink ports, which are located on SFP transceiver
modules that plug into the front panel.
Table B-4 1GE SFP Transceiver Modules
Product ID Description
Copper Modules
GLC-SX-MM 1000BASE-SX SFP transceiver module for multimode fiber
(MMF), 850-nm wavelength, LC connector
GLC-LH-SM 1000BASE-LX/LH SFP transceiver module for MMF and
single-mode fiber (SMF), 1300-nm wavelength, LC connector
GLC-ZX-SM 1000BASE-ZX SFP transceiver module for SMF,
1550-nm wavelength, LC connector
GLC-T 1000BASE-T SFP transceiver module for Category 5, 5e, or 6
copper wire; 10/100/1000-Mbps RJ-45 connector
GLC-BX-D 1000BASE-BX10 SFP module for single-strand SMF,
1490-nm TX/1310-nm RX wavelength (downstream use in
bidirectional single fiber applications), with Digital Optical
Monitoring (DOM), LC connector
GLC-BX-U 1000BASE-BX10 SFP module for single-strand SMF,
1310-nm TX/1490-nm RX wavelength (upstream use in
bidirectional single fiber applications), with DOM, LC connector
Fiber Modules
SFP-GE-S 1000BASE-SX SFP transceiver module for MMF,
850-nm wavelength, extended operating temperature range and
DOM support, LC connector
SFP-GE-L 1000BASE-LX/LH SFP transceiver module for MMF and SMF,
1300-nm wavelength, extended operating temperature range and
DOM support, LC connector
SFP-GE-T 1000BASE-T SFP transceiver module for Category 5, 5e, or 6
copper wire, extended operating temperature range and DOM
support (NEBS 3ESD); 10/100/1000-Mbps RJ-45 connector
Table B-5 1GE Cabling Specifications
SFP Module
(Product ID)
Wavelength
(nm)
Fiber Type
(MHz km)
Core Size
(micron)
Modal Bandwidth
(MHz km)
Maximum Cable
Distance
GLC-SX-MM
SFP-GE-S
850 MMF
1
62.5
62.5
50
50
160
200
400
500
722 ft (220 m)
902 ft (275 m)
1640 ft (500 m)
1804 ft (550 m)
GLC-LH-SM
SFP-GE-L
1300 MMF
2
62.5
50
50
500
400
500
1804 ft (550 m)
1804 ft (550 m)
1804 ft (550 m)
SMF
3
9/10 — 6.2 mi (10 km)
