Implementing Multicast Routing on Cisco IOS XR Software Cisco ASR 9000 Series Routers
How to Implement Multicast Routing
MCC-39
Multicast Configuration Guide
OL-
Step 10
end
or
commit
Example:
RP/0/0/CPU0:router(config-igmp)# end
or
RP/0/0/CPU0:router(config-igmp)# commit
Saves configuration changes.
• When you issue the end command, the system prompts
you to commit changes:
Uncommitted changes found, commit them before
exiting(yes/no/cancel)?
[cancel]:
– Entering yes saves configuration changes to the
running configuration file, exits the configuration
session, and returns the router to EXEC mode.
– Entering no exits the configuration session and
returns the router to EXEC mode without
committing the configuration changes.
– Entering cancel leaves the router in the current
configuration session without exiting or
committing the configuration changes.
• Use the commit command to save the configuration
changes to the running configuration file and remain
within the configuration session.
Step 11
show {igmp | mld} [old-output] nsf
Example:
RP/0/0/CPU0:router# show igmp nsf
(Optional) Displays the state of NSF operation in IGMP or
MLD.
Step 12
show mfib [ipv4 | ipv6] nsf [location node-id]
Example:
RP/0/0/CPU0:router# show mfib nsf
(Optional) Displays the state of NSF operation for the
MFIB line cards.
Step 13
show mrib [ipv4 | ipv6] [old-output] nsf
Example:
RP/0/0/CPU0:router# show mrib nsf
(Optional) Displays the state of NSF operation in the MRIB.
Step 14
show pim [ipv4 | ipv6] nsf
Example:
RP/0/0/CPU0:router# show pim nsf
(Optional) Displays the state of NSF operation for PIM.
Command or Action Purpose
