Cisco XR 12000 Series Hardware Installation Guide

1-16
Cisco XR 12000 Series Router SIP and SPA Hardware Installation Guide
OL-17438-04
Chapter 1 Overview: Cisco XR 12000 Series Router SPA Interface Processors
Cisco XR 12000 SIP-601 Overview
Figure 1-15 shows a Cisco XR 12000 SIP-601 with 2 SPAs installed. The left SPA slot is subslot 0 and
the right SPA slot is subslot 1. If one dual-width SPA is installed, it is recognized as being in subslot 0.
Figure 1-15 Subslot Locations for the 1-Port 10-Gigabit Ethernet SPA
SPA Interface Addresses on the Cisco XR 12000 SIP-601
A Cisco 12000 Series Router identifies a SPA interface address by its SIP slot number, SPA subslot, and
port number on the SPA, in the format slot/subslot/port. Subslots and ports are numbered starting from
0, so each Cisco XR 12000 SIP-601 has two subslots 0 (left) and 1 (right). For example, the interface
address of a 1-port SPA located in the second SIP subslot, where the SIP is inserted into router line card
slot 3 is 3/1/0. Figure 1-16 shows the slot, subslot, and port locations for the 1-Port 10-Gigabit Ethernet
SPA and the 10-Port Gigabit Ethernet SPA.
Table 1-16 Subslot Locations for the 1-Port 10-Gigabit Ethernet SPA
Call Out Number Description
1 Subslot 0
2 Subslot 1
12000-SIP-600
0
116872
STATU S
S
P
A
-1
X
T
E
N
G
E
-X
F
P-A
A
C
T
IV
E
/
L
IN
K
S
P
A
1
0
X
1
G
E
-A
S
T
A
T
U
S
4
9
3
8
2
7
1
6
0
5
A
/L
A
/L
A
/L
A
/L
A
/L
A
/L
A
/L
A
/L
A
/L
A
/L
1
2
