— 17 —
* SPECIAL REMARKS CONCERNING PAPER
SHAPE: The beginning of winding (end part of the inside diameter) should satisfy the following (Refer
to Drawing A):
1. Free of fold and well aligned to inside diameter
2. Free of flaps
3. Not adhered to core part (if there is one)
RECOMMENDED PAPER:
Single paper ... 45 ~ 55 kg/1,000 sheets/1,091 × 788 mm
Copy paper ... Non-carbon paper/original (34 kg-paper) + copy 1 sheet (34 kg-paper)
Total thickness ... 0.13 mm or less
The beginning of winding Drawing A Not accepted
To Next Page
